STANDING SEAM SYSTEM

European Profiles Standing Seam System

EurozipTM is becoming increasingly popular in both residential and commercial buildings, thanks to its versatility, durability, longevity and energy efficiency properties. Boasting variety of width, tapering and curving capabilities, this standing seam roofing system has the ability to adapt to buildings of any geometry and shape, making it an ideal choice for modern architectural designs.


Standing seam roof panels has raised metal seams that are joined with concealed fasteners. These panels are attached to the building structure with high-strength metal clips without screws piercing through the sheets. This not only gives a clean, sleek look to the roof profile, but also eliminates possibilities of seam leakages and offers a superior waterproofing system.


The EurozipTM range of standing seam profile also offers the flexibility of on-site roll forming, providing installers the control to form and customise panels at the project site. The colour and material of this roofing system can also be customised to one’s needs and preferences.


The EurozipTM series come in few variation - EurozipTM 25, EurozipTM 38, EurozipTM 65, Eurolock 25, Eurolock 38, Eurosnap 25, and Eurosnap 38. EurozipTM 65 can be paired with ST clips of varying heights, allowing thermal and acoustic enhancements. It also has the ability to be engineered with solar retention options.


Model

Effective Width

Rib Height

Thickness (BMT)

Material Substrate

Range of colors

EuroLock 25 / 38

300mm to 800mm

25mm / 38mm

0.42mm to 1.0mm

Aluminium / Zincalume / Galvanised Steel

HPS200 Ultra / Prisma / Clean Colorbond / PVDF / Polyester / Super Durable Polyester

EUROZIP 1.png

Model

Effective Width

Rib Height

Thickness (BMT)

Material Substrate

Range of colors

EuroZipTM 25 / 38

300mm to 800mm

25mm / 38mm

0.42mm to 1.0mm

Aluminium / Zincalume / Galvanised Steel

HPS200 Ultra / Prisma / Clean Colorbond / PVDF / Polyester / Super Durable Polyester


Model

Effective Width

Rib Height

Thickness (BMT)

Material Substrate

Range of colors

EuroSnap 25 / 38

300mm to 800mm

25mm / 38mm

0.42mm to 1.0mm

Aluminium / Zincalume / Galvanised Steel

HPS200 Ultra / Prisma / Clean Colorbond / PVDF / Polyester / Super Durable Polyester

EUROZIP 65.png

Model

Effective Width

Rib Height

Thickness (BMT)

Material Substrate

Range of colors

EuroZip TM65

400mm

65mm

0.42mm to 1.0mm

Aluminium / Zincalume / Galvanised Steel

HPS200 Ultra / Prisma / Clean Colorbond / PVDF / Polyester / Super Durable Polyester
